DC1-5V Current Transducer

BA1-5V

  • Consumption≤1W
  • Overload≤135%
  • Precision 0.5 class
  • Safety IEC688:1992
Chat Online Leave Message

Highlight

What’s the Function of the Current Transducer?

Theory

  • Electromagnetic Induction

 Input

  • AC 0-600A

Output

  • 1-5V
  • 0-5V

Application

  • Automation field

Specification

What’s the Specification of Acrel BA series DC1-5V Current Transducer?

Specification BA05-AI/V BA10-AI/V BA20-AI/V BA50-AI/V
Inner Size Φ5 mm Φ10 mm Φ20 mm Φ50 mm
Input Current AC 0-(0.5~10)A AC 0-(8~50)A AC 0-(40~200)A AC 0-(60~600)A
Output Signal DC1-5V, 0-5V

Parameter

What’s the Parameter of the Current Transducer?

Accuracy 0.5%
Response time Average Value ≤ 350ms,  True RMS ≤ 100ms
Auxiliary Power DC12V(10-15V); DC24V(18-30V);AC220V
Load Resistance Current Output ≤ 500Ω，Voltage Output ≥ 1KΩ
Withstand AC2000V
Operation Temperature -10℃ ~ +55℃
Temperature Drift Coefficient ≤ 200ppm/℃
Altitude ≤ 2500m
Humidity ≤ 90% RH
Installation Din-rail 35mm
